Designing internal manual sliding doors with an elegant lightness and moving them effortlessly is now also possible with door leaves of up to 120 kg. The fitting technology of the Levolan 120 is completely integrated into the track. The compact modular sliding door system, with its discreet and linear appearance and a narrow track of only 50 millimetres high, adapts to any installation situation. The Levolan SoftStop draw-in damping, which can also be integrated into the track, provides safety and comfort up to 120 kg. The sliding door leaves are guided gently and safely into the end position. Hitting the frame and the risk of trapping fingers is almost eliminated. Specially designed carrier rollers ensure an excellent load distribution and smooth running characteristics. Removal protection is automatically activated when the height of the door leaf is adjusted, thus providing additional safety, almost by itself. The Levolan 120's clamping carriage is designed for glass thicknesses of 10 - 12.76 millimetres, meaning that the sliding door system can also be realised with door leaves made from laminated safety glass. The Levolan Smart fix installation system makes the installation fast and straightforward. Only one hollow-set-screw and one open-ended spanner are required for securing the installation. The carriage with the leaf can be conveniently mounted on the track and calibrated from the front.
Twice as strong but no bigger: discreet appearance with the smallest possible space requirements - The new GEZE Levolan 120 sliding door system
GEZE at FENSTERBAU FRONTALE 2016 - The trade show. Windows. Door. Facade / 16 - 19 March 2016, NürnbergMesse, Nuremberg, Hall 2, Stand 2-424
Designing internal manual sliding doors with an elegant lightness and moving them effortlessly is now also possible with door leaves of up to 120 kg. The fitting technology of the Levolan 120 is completely integrated into the track. The compact modular sliding door system, with its discreet and linear appearance and a narrow track of only 50 millimetres high, adapts to any installation situation. The Levolan SoftStop draw-in damping, which can also be integrated into the track, provides safety and comfort up to 120 kg. The sliding door leaves are guided gently and safely into the end position. Hitting the frame and the risk of trapping fingers is almost eliminated. Specially designed carrier rollers ensure an excellent load distribution and smooth running characteristics. Removal protection is automatically activated when the height of the door leaf is adjusted, thus providing additional safety, almost by itself. The Levolan 120's clamping carriage is designed for glass thicknesses of 10 - 12.76 millimetres, meaning that the sliding door system can also be realised with door leaves made from laminated safety glass. The Levolan Smart fix installation system makes the installation fast and straightforward. Only one hollow-set-screw and one open-ended spanner are required for securing the installation. The carriage with the leaf can be conveniently mounted on the track and calibrated from the front.
